Technical Specification▼

Source

Lamp: LED

Optical system

Zoom range: 4° - 28°

Main features

Colour mixing: RGBW

Beam , Wash ,Spot,Compact design and working fast

Strobe: Strobe effect with variable speed(0.3-20Hz)

Dimmer: Smooth dimmer from 0-100%

Prism: 3-facet rotating prism with continuous rotation in one direction

Frost: one Frost wheel

LED life expectancy: min,50000 hrs

Control

LCD display, 180degree Reversal Available

Control mode: DMX 512, Auto, Master-slave, Sound

Channel: 21/27CH

Thermal specification

Maximum ambient temperature: 40 °C(104℉)

Maximum surface temperature: 90 °C(194℉)

Minimum operating temperature: -20 °C(68℉)

Electrical specification and connections

Power supply: Electronic auto-ranging

Input voltage range: 100-240 V, 50/60 Hz

Power consumption: 120 W

LED Source: :120W LED White;

Power connector: Powercon In/Out

Data connector: 3pin XLR In/Out

Movement

Pan Tilt movement range: 360° infinite rotating

Approvals

CE Compliant

ROSH Compliant

Mechanical specification

Height:395mm (15.5")

Width: 194mm (7.6")

Depth: 290mm (11.4")

Weight: 9.5kg

Ingress protection rating: IP20

Included items

User Manual

Power Cable

Signal Cable

Omega

Optional accessories

Lamp Hook

Safety Wire
