Source
Lamp: LED
9×15W RGBW LEDs,
LED Average Life : 50,000 h
Ballast: Electronic
Optical system
Zoom : 4°-60° Electronic Zoom Range
Main features
Individual LED control for each parameter
0-100% linear electronic dimmer
Adjustable speed stop/strobe effect, with instantaneous blackout
Three operating modes: wash, beam, FX (Kaleido effects)
Bi-directional Rotating Front Lens
Digital Wash-Beam Framing effect
Beam edge softening control (in Wash mode)
Pixel Patterning Macros with enhanced control
Control
3 DMX Modes : 21CH Standard , 35/78/97/92 CH Extended , 23CH Normal
Electrical specification and connections
Power supply :100-240V 50/60Hz
Power : 350W
DMX signal connection: 3 Pin XLR input and output
Power Con In and Out
Movement
Pan : 540° , 16 bit
Tilt : 210° , 16 bit
Approvals
CE Compliant
ROSH Compliant
Mechanical specification
Net Weight : 15KG
Size:494*358*253
Included items
User Manual
Power Cable
Signal Cable
Omega
Optional accessories
Lamp Hook
Safety Wire
