Technical Specification▼

Source

Lamp: LED

Main features

Strobe: 20 Hz

Beam angle:15° 25° 40° optional

High resolution electronic dimming: 0 - 100%

Control

Setting & Addressing: two-row LCD display & 4 control buttons

Control Mode: DMX512,Master-slave,Sound,Auto

Channel: 7CH

Thermal specification

Maximum ambient temperature: 40 °C(104℉)

Maximum surface temperature: 90 °C(194℉)

Minimum operating temperature: -20 °C(68℉)

Electrical specification and connections

Input voltage range: 100-240 V, 50/60 Hz

Power consumption: 60 W

LED Source: 54pcs*1W RGBW LED （R12、G18、B18、W6）

Power connector in/out: PG

DMX data in/out: Locking 3-pin XLR

Approvals

CE Compliant

ROSH Compliant

Mechanical specification

Weight: 1.3kg

Protection rating: IP20

Carton Packing size:  250*190*230mm (1pc/CTN)

Included items

User Manual

Signal Cable

Optional accessories

Lamp Hook

Safety Wire

Omega
