Technical Specification:▼
Source
Lamp: LED
Ballast: Electronic
Optical system
Beam angle:16°
Main features
Control mode : DMX 512, master-slave , sound , Auto, wireless
Colors: 7 + white, split colors, continuous scroll at variable speeds
Rotation gobo wheel: 6 + open (5 aluminum + 1 glass), rotating, interchangeable, slot-n-lock, continuous scroll at variable speeds
Prism: 3-facet round, bidirectional rotation at variable speeds
Strobe Rate: 0 to 15 Hz
Control
LCD display
Control mode:DMX 512, master-slave and sound activated or auto operation
Channel:11/13 DMX Channels USITT DMX-512
Thermal specification
Maximum ambient temperature: 40 °C(104℉)
Maximum surface temperature: 90 °C(194℉)
Minimum operating temperature: -20 °C(68℉)
Electrical specification and connections
Power supply: Electronic auto-ranging
Input voltage range: 100-240 V, 50/60 Hz
Power consumption: 100 W
LED Source: LED 60W White
PowerCon IN/OUT
DMX connector : 3-pin XLR connectors IN/OUT
Battery:
Battery type: Lithium Ion
Battery Charge Time: 6 hours
Battery Life: (all on) 4 hours
Battery Power: 21V, 15Ah
Movement
Pan/Tilt movement: Pan 540,Tilt 270
Approvals
CE Compliant
ROSH Compliant
Mechanical specification
Weight: 13.25 kg
Ingress protection rating: IP20
Included items
User Manual
Power Cable
Signal Cable
Omega
Optional accessories
Lamp Hook
Safety Wire
