Technical Specification▼

Source

LED: 4*10W Led COB Warm white, each Led Pixel control

Light color:  WW

Optical system

Manual zoom:6-37°

Color temperature:2700K±100

Main features

LED life time: 50000hours

Light Head adjustable: Horizontal 360°, Vertical 90°

Dimmer : 0-100% linear adjustable

Strobe: 1-25times/s

Housing color : black

Control

Control panel : LCD display

Channel: 5CH

Control mode:DMX512 , Master/Slave , Auto,Sound, Wireless,remote, RDM

Thermal specification

Maximum ambient temperature: 40 °C(104℉)

Maximum surface temperature: 90 °C(194℉)

Minimum operating temperature: -20 °C(68℉)

Electrical specification and connections

Input voltage range: 100-240 V, 50/60 Hz

Power consumption: 40W

Power connector : Powercon in

DMX connector: 3-pin dmx IN/OUT

Control panel : LED display, with 4buttons

Housing material : aluminum alloy

Install: With three strong Magnet for quick installation; With 2 Clamp position for hang to truss.

Approvals

CE Compliant

ROSH Compliant

Mechanical specification

Weight: 3.33kg

Dimension:660*74*238mm

Ingress protection rating: IP20

Battery

Battery type: Lithium Ion

Battery Power: 11.1V，8.8Ah

Battery Charge Time: 6 hours(full power)

Battery Life: (all on) 3hours, (single Led single color) 12hours

Included items

User Manual

Power Cable

Signal Cable

Optional accessories

Lamp Hook

Safety Wire
