Source

Light source: 9x 10W  RGBWA+UV 6in1 LED

Beam Angle: 15/25/45°

Main features

Colour mixing: RGBWA+UV 6in1

Wash , Strobe  Effect

Electronic strobe effect with variable speed up to 24 Hz, pre-programmed random strobe & pulse effects

High resolution electronic dimming: 0 - 100%

Display: Touch screen

Suitable for all types of production in party,event,wedding,dj, disco...

Control

Setting & Addressing: two-row LCD display & 4 control buttons

Control mode: DMX 512, Auto, Master-slave, Sound,Wireless,

Channel: 6/10CH

Thermal specification

Maximum ambient temperature: 40 °C(104℉)

Maximum surface temperature: 90 °C(194℉)

Minimum operating temperature: -20 °C(68℉)

Electrical specification and connections

Power supply: Electronic auto-ranging

Input voltage range: 100-240 V, 50/60 Hz

Power consumption: 90 W

L

Battery

Battery type: Lithium Ion

Battery Charge Time: 6 hours(full power)

Battery Life: (all on) 4hours, (single Color) 24hours

Battery Power: 12V, 25Ah

Wireless effective distance: 400meters

Approvals

CE Compliant

ROSH Compliant

Mechanical specification

Height:210 mm

Width: 230mm

Lenth: 180mm

Weight: 4.5kg

Ingress protection rating: IP20

Included items

User Manual

Power Cable

DMX Cable
