Source

Lamp: 300W LED

Optical system

Beam Angle: 2-40 degrees

Color temperature: 8800K

Main features

Colors wheel :13 colors+white,With half color,Two-way rainbow effect

Static gobo wheel: 11 gobos+open,variable shake speed, and bidirectional rotation

Rotation goboe: 9 gobos+open

Prism wheel 1:Independent 3 facet rotation prism,can be superimposed with Prsim 2

Prism wheel 2: Independent 6 linear rotation prism,can be superimposed with Prism 1

Frost: Light+heavy frost

Cyan: 0-100%

Magenta: 0-100%

Yellow: 0-100%

Control

Setting & Addressing:LCD display with 5 buttons

Control Mode:DMX512, Master-slave,Auto,RDM

Channel: 26CH

Electrical specification and connections

Input voltage range: 100-240 V, 50/60 Hz

Power consumption: 300W

Led life:20000Hrs

Power connector in/out: Ture one In/Out

DMX data in/out: 3pin DMX IN/OUT

Dimmer:0-100% linear dimmer

Zoom: Motorised 8 or 16 bit

Focus: Montorised 8 or 16 bit

Approvals

CE Compliant

ROSH Compliant

Mechanical specification

Weight: 18.5kg

Product size: 388*256*533mm

Ingress protection rating: IP65

Included items

User Manual

Power Cable

Signal Cable

Omega

Optional accessories

Lamp Hook

Safety Wire
