Technical Specification▼

Source

Lamp: LED

Colour Temperature: 6000 K

Ballast: Electronic

Main features

Beam , Dyeing,Zoom,Compact design and working fast

Strobe:Independent strobe channel, 1-13times/s, speed adjustable

Dimmer: Smooth dimmer from 0-100%

Motor: 8pcs

Prism:8-facet prism rotating ,16-facet prism rotating

Colorful wheel: 1 seven colors wheel

Color Wheel:13 colors+white

Gobo Wheel:11 gobos+white,gobo-flow effect,gobo shake

LED life expectancy: min,50000 hrs

Control

LCD display, 180degree Reversal Available

Control mode: DMX 512, Auto, Master-slave,Sound

Channel: 16/20CH

Thermal specification

Maximum ambient temperature: 40 °C(104℉)

Maximum surface temperature: 90 °C(194℉)

Minimum operating temperature: -20 °C(68℉)

Electrical specification and connections

Power supply: Electronic auto-ranging

Input voltage range: 100-240 V, 50/60 Hz

Power consumption: 150 W

LED Source: :80w LED

Power connector: Powercon In/Out

Data connector: 3pin XLR In/Out

Movement

Pan/ Tilt movement range: 540/270 degrees

Approvals

CE Compliant

ROSH Compliant

Mechanical specification

Height: 290mm (11.4")

Width:250mm (7.1")

Depth: 460mm (18.1")

Weight:11.17kg

Ingress protection rating: IP20

Included items

User Manual

Power Cable

Signal Cable

Omega

Optional accessories

Lamp Hook

Safety Wire
