Optical System

Input power:AC100-240V 50/60 Hz

Power consumption :600 W

Specification

18*40W LED BAR RGBW

LED life expectancy: min. 20.000 hours

Display: Touch display

IP Rate:IP65

Color mixing mode RGBW

Individual control of each RGBW pixel

Variable CTO: 2.700K - 8.000K

Motorized zoom

2 independent zoom zones

Pre-programmed random strobe & pulse effects

Electronic strobe effect with variable speed up to 20 Hz

High resolution electronic dimming: 0 - 100%

Tilt movement: 205°

16 bit movement resolution

Electrical /THERMAL

Power in/out connector: Ture One in/out

DMX in/out: 3-pin XLR

Control and Programming

DMX Protocol modes: 4

Control channels: 16/27/76CH/88CH

Mechanical Specification

Length: 1091MM

Width: 121MM

Height: 319.1MM

Weight: 24.01kg

Package

2in1 Flycase Size: 1070*530*530MM,, weight: 65KG

Carton size: 1050*220*370MM,weight: 26KG( 1pcs in one carton)

Approvals Certificate

CE Compliant

ROSH Compliant

Included items

User Manual

Power Cable

DMX Cable

Omega
