Ultimate Outdoor Beam Wash Spot LED 500W Moving Head Light | IP65 Rated |

500W Beam Spot Wash LED IP65 with CMY CTO

SKU: 218C105

Light Source
LED 500W White

Light Output
6013 lx@20m

Zoom Range
2.5-45degree


Availability:
Quantity:
  • CRUISER 500



Product Video






Technical Specification

The IP500 is a powerful yet compact IP65 LED BSW fixture offering outstanding projection and beam qualities in any environment. When the distance is 20 meters,Providing up to 6013lumens output from its custom-designed Peak Field 500W 8000K LED engine, the IP500 is the ideal fixture for any outdoor or indoor events requiring class-leading output,bright and powerful beams,  as well as stunningly precise gobos and colors. It's a fast zoom range from 2.5° to 45° out of an impressively ,make outdoor lighting complications and stress a thing of the past!


Source

Lamp: 500W LED



Optical system

Zoom range: 2.5-45°


Main features

Beam Wash Spot 3IN1

CMY Wheel: Cyan, Magenta, Yellow, Smooth color mixing

CTO

Zoom range: 2.5-45degree

Electronic strobe effect with variable speed up to 25 Hz, pre-programmed random strobe & pulse effects

High resolution electronic dimming: 0 - 100%

2 Prisms: with rotate function, variable speed

Color wheel: 13 colors+white

Static gobo wheel: 12 gobos+white

Rotate gobo wheel: 7 gobos+white

Frost: 1 Frost wheel

Animation: 1 animation wheel


Control

Setting & Addressing: two-row LCD display & 5 control buttons

Control mode: DMX 512, Auto, Master-slave, RDM

Channel:29CH


Thermal specification

Maximum ambient temperature: 40 °C(104℉)

Maximum surface temperature: 90 °C(194℉)

Minimum operating temperature: -20 °C(68℉)


Electrical specification and connections

Input voltage range: 100-240 V, 50/60 Hz

Power consumption: 650 W

Power connector in/out: IP power CON/Out

DMX data in/out: Locking 3+5-pin XLR


Movement

Pan movement:540 degree

Tilt movement: 270 degree


Approvals

CE Compliant

ROSH Compliant


Mechanical specification

N.W.: 35 kg

Product size:390*310*708mm

Packing size:570*488*792mm(1pcs/CTN)

G.W.: 38kg

Ingress protection rating: IP65


Included items

User Manualx1

Power Cablex1

Signal Cablex1

Omegax2


Optional accessories

Lamp Hook

Safety Wire


Product Description


Ultimate Outdoor Beam Moving Head Light

The LEAHUA Ultimate Outdoor Beam Moving Head Light is a high-performance lighting fixture designed for demanding outdoor and indoor applications. This versatile fixture offers a wide range of features, including:


  • Powerful Output: Equipped with a 500W LED engine, delivering up to 6013 lumens of brightness.

  • Versatile Beam: Offers beam, wash, and spot effects, providing flexibility for various lighting designs.

  • Precise Control: Features a CMY color mixing system, electronic dimming, and multiple gobo wheels for stunning visual effects.

  • Robust Construction: IP65 rated for outdoor use and can withstand harsh weather conditions.

  • Smooth Movement: Offers a wide pan and tilt range for dynamic lighting effects.


Key Features:

  • Versatile Beam Shaping: Create a variety of beam shapes and sizes with the adjustable zoom range.

  • Precise Color Mixing: Achieve a wide range of colors using the CMY color wheel.

  • Dynamic Effects: Utilize the electronic strobe, rotating prisms, and animation wheel for eye-catching visual effects.

  • Robust Construction: Designed for outdoor use with an IP65 rating.

  • Easy Control: Simple to operate with DMX 512 control.

led 500w moving head

Product Specifications

Parameter Value
Light Source 500W LED
Zoom Range 2.5-45°
Color Mixing CMY+12 colors+white
Strobe Electronic, variable speed
Gobo Wheels Static: 12, Rotating: 7
Prism 4 face prism+4 liner prism with rotating
Control DMX 512, Auto, Master-slave, RDM
Channels 29
Power Consumption 650W
Voltage 100-240V, 50/60Hz
IP Rating IP65
Net Weight 35kg
Dimensions 390*310*708mm


Ideal for:


  • Stage lighting

  • Event lighting

  • Architectural lighting

  • Outdoor installations


Key Features of the Ultimate Outdoor Beam Moving Head Light

Here are the key features of the Ultimate Outdoor Beam Moving Head Light:


1. Powerful Performance: Equipped with a 500W LED engine, this fixture delivers exceptional brightness and clarity.

2. Versatile Beam Effects: Offers a wide range of beam shapes, including spot, wash, and beam effects, thanks to its advanced optical system.

3. Precise Color Mixing: The CMY color mixing system enables smooth color transitions and vibrant hues.

4. Dynamic Effects: Features electronic strobe effects, rotating prisms, and animation wheels for captivating visual displays.

5. Robust Construction: IP65-rated housing ensures durability and reliability in outdoor environments.

6. Flexible Control: Compatible with DMX 512, allowing for precise control over all functions.

7. Efficient Cooling System: Maintains optimal performance even in demanding conditions.

8. Compact Design: Lightweight and easy to install and transport.


Application Scenarios for LEAHUA Ultimate Outdoor Beam Moving Head Light

· Live Performances: Create dynamic and visually stunning lighting effects for concerts, music festivals, and other live events.

· Theater Productions: Enhance theatrical productions by providing versatile lighting options for scene changes and atmosphere.

· Music Festival Performances: Synchronize lighting with music and choreography to create captivating visual displays.


FAQ (Frequently Asked Questions)

· What is the maximum output of the Ultimate Outdoor Beam Moving Head Light?

The maximum output of the light is 6013 lumens.

· What is the zoom range of this fixture?

The zoom range is 2.5-45°.

· What color mixing system is used in this light?

It utilizes a CMY color mixing system.

· What types of effects can this light produce?

It can produce various effects, including beam, wash, and spot, as well as electronic strobe, rotating prism, and animation effects.

· Is this light suitable for outdoor use?

Yes, it is IP65 rated, making it suitable for outdoor applications.

· How is this light controlled?

It can be controlled via DMX 512, auto, master-slave, or RDM modes.

· How many channels does this light have?

It has 29 channels.

· What are the primary applications of this light?

It is ideal for live performances, theater productions, dance performances, corporate events, nightclubs, houses of worship, theme parks, architectural lighting, film and television, and outdoor events.

· Can this light be used for concert lighting?

Yes, it can be used to create dynamic and visually stunning lighting effects for concerts.

· Can this light be used for architectural lighting?

Yes, it can be used to highlight architectural features and create striking visual displays.

· What is the power consumption of this light?

The power consumption is 650W.

· What is the net weight of this light?

The net weight is 35kg.
