Technical Specification▼

 Source

Light Source: 12pcs LED each 60 W, RGBW 4in1

Ballast: Electronic

Optical system

Beam Angle 3.2°-7.4°

Field Angle 3.6°-13.3°

Control

Colorful LCD display

Control mode: DMX 512, Auto, Master-slave,Sound

DMX Channels: CH20.CH53.CH169A.CH169B.CH53.CH101.CH155.CH179

Thermal specification

Maximum ambient temperature: 40 °C(104℉)

Maximum surface temperature: 90 °C(194℉)

Minimum operating temperature: -20 °C(68℉)

Electrical specification and connections

Input Voltage: AC100-240V 50/60Hz

Power: 850W

Cooling : Efficient low noise fan cooling system

Dimmer: 0-100% electronic

Shutter: Max 10Hz electronically

Power connector : PowerCON IN/ OUT

DMX connector : 3-pin XLR connectors IN/OUT

Movement

Tilt movement: 240^o

Approvals

CE Compliant

ROSH Compliant

Mechanical specification

Dimension: 1000x210x320mm

Weight:29.5kg

Ingress protection rating: IP65

Included items

User Manual

Power Cable

Signal Cable

Omega

Optional accessories

Lamp Hook

Safety Wire
