Technical Specification▼

Source

Light source: 300W LED white color

Colour Temperature: 4000K

LED life: 50000 hours

Optical system

Zoom angle: 2-40°

Main features

Beam Spot Wash Effects

Ultra-thin base

High resolution electronic dimming: 0-100% linear dimmer

Frost: one frost wheel

Color wheel: 9 colors+white

Static Gobo wheel: 8 gobos+white

Rotate Gobo wheel: 7 gobos+white

Prism: 3-face prism rotatiing

Control

Control mode: DMX 512, Auto, Master-slave, Sound

Channel: 22CH

Thermal specification

Maximum ambient temperature: 40 °C(104℉)

Maximum surface temperature: 90 °C(194℉)

Minimum operating temperature: -20 °C(68℉)

Electrical specification and connections

Input voltage range: 100-240 V, 50/60 Hz

Power: 300W

Power connector in/out: Locking Seetronic in/out

DMX data in/out: Locking 3-pin +5-pin XLR

Approvals

CE Compliant

ROSH Compliant

Mechanical specification

Height: 545mm

Width:  381mm

Depth:  240mm

Weight: 17kg

Ingress protection rating: IP65

Included items

User Manual

Power Cable

Signal Cable

Optional accessories

Lamp Hook

Safety Wire

Omega
