Technical Specification▼

Source

Light source type: 150W/200W/300W

LED life expectancy: min. 50,000 hours

Colour rendition: CRI≥90

Optical system

Zoom range: 15-50°

Main features

LED Color: CW+WW 2in1(200W)/RGBW 4in1(200W)/CW or WW (150W/200W/300W) COB LED

Dimmer: 0~100% linearly adjustable

Zoom by manual/ Auto zoom(optional)

House Material: Aluminum Alloy

House Color: Black

Control and programming

Setting & Addressing: two-row LCD display & 4 control buttons

Control mode: DMX 512, mater and slave, auto running, sound mode

Control channels:

DMX auto zoom: 2/5 CH (single color), 3/7 CH (2in1), 5/10 CH (RGBW)

Manual zoom: 1/3CH(single color), 2/5CH(2in1), 4/8CH(RGBW)

Thermal specification

Maximum ambient temperature: 40 °C

Maximum surface temperature: 60 °C

Minimum operating temperature: -20 °C

Electrical specification and connections

Power supply: Electronic auto-ranging

Input voltage range: AC100V-240V  50-60Hz

Power consumption: Max. 150W/200W/300W

Power connector in/out: powerCON in/out

DMX data in/out: Locking 3-pin XLR

Approvals

CE Compliant

ROSH Compliant

Mechanical specification

Net weight: 8.5kgs

Gross weight: 11kgs

Packing Size: 58x32.5x32cm (1pc/carton)

Included items

User Manual

Power Cable

DMX Cable
