Technical Specification▼

Source

Light source type: 60W

LED life expectancy: min. 50,000 hours

Colour rendition: CRI≥95

Optical system

Zoom range: 20-35°

Main features

LED Color: CW+WW 2in1/RGBW 4in1/CW or WW COB LED

Dimmer: 0~100% linearly adjustable

Zoom by manual

House Material: Die-casting Aluminum

House Color: Black

Control and programming

Setting & Addressing: two-row LCD display & 4 control buttons

Control mode: DMX 512, mater and slave, auto running, sound mode

Control channels:1/3CH(single color), 2/5CH(2in1), 4/8CH(RGBW)

Thermal specification

Maximum ambient temperature: 40 °C

Maximum surface temperature: 60 °C

Minimum operating temperature: -10 °C

Electrical specification and connections

Power supply: Electronic auto-ranging

Input voltage range: AC100V-240V  50-60Hz

Power consumption: Max. 60W

Approvals

CE Compliant

ROSH Compliant

Mechanical specification

Net weight: 2.5kgs

Gross weight: 3.5kgs

Packing size: 44.5*22.5*18.5cm(1pc/carton)

                     49*47*40cm(4pc/carton)

Included items

User Manual

Power Cable

DMX Cable
